Detailed Description
Typedef Documentation
typedef baci::ActionRequest(Mount::* Mount::ActionFunction)(baci::BACIComponent *component_p, const int &callbackID, const CBDescIn &descIn, baci::BACIValue *value_p, Completion &completion, CBDescOut &descOut) [private, inherited] |
Definition of ActionFunction (member function of Mount class) ActionFunction is used to run the asynchronous methods from within invokeAction(...) without actually having to specify calls to each ...Action(...) method. This is easily accomplished since all ...Action(...) methods return an baci::ActionRequest.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
typedef baci::ActionRequest(SlowMount::* SlowMount::ActionFunction)(baci::BACIComponent *component_p, const int &callbackID, const CBDescIn &descIn, baci::BACIValue *value_p, Completion &completion, CBDescOut &descOut) [private, inherited] |
Definition of ActionFunction (member function of Mount class) ActionFunction is used to run the asynchronous methods from within invokeAction(...) without actually having to specify calls to each ...Action(...) method. This is easily accomplished since all ...Action(...) methods return an baci::ActionRequest.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
Function Documentation
| virtual void FilterWheel::aboutToAbort | ( | ) | [virtual, inherited] |
Called when due to some error condition the component is about to be forcefully removed some unknown amount of time later (usually not very much...). The component should make an effort to die as neatly as possible. Because of its urgency, this method will be called asynchronously to the execution of any other method of the component. If this method is overwritten in a chain of subclasses, the developer might need to make sure that all activities performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a constructor chain. In this class the default implementation only sets the state of the component to acscomponent::ACS::ACS::COMPSTATE_ABORTING
- Returns:
- void
| virtual void LampWheel::aboutToAbort | ( | ) | [virtual, inherited] |
Called when due to some error condition the component is about to be forcefully removed some unknown amount of time later (usually not very much...). The component should make an effort to die as neatly as possible. Because of its urgency, this method will be called asynchronously to the execution of any other method of the component. If this method is overwritten in a chain of subclasses, the developer might need to make sure that all activities performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a constructor chain. In this class the default implementation only sets the state of the component to acscomponent::ACS::ACS::COMPSTATE_ABORTING
- Returns:
- void
| virtual ACS::ROdouble_ptr Mount::actAz | ( | ) | [virtual, inherited] |
Returns a reference to the actAz property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property actAz
| virtual ACS::ROdouble_ptr SlowMount::actAz | ( | ) | [virtual, inherited] |
Returns a reference to the actAz property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property actAz
| virtual ACS::ROdouble_ptr Mount::actEl | ( | ) | [virtual, inherited] |
Returns a reference to the actEl property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property actEl
| virtual ACS::ROdouble_ptr SlowMount::actEl | ( | ) | [virtual, inherited] |
Returns a reference to the actEl property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property actEl
| virtual void FilterWheel::adjust | ( | int | , | |
| ACS::CBvoid_ptr | , | |||
| const ACS::CBDescIn & | ||||
| ) | [virtual, inherited] |
Move the wheel of the specified number of step
- Parameters:
-
the step to move the wheel
| virtual baci::ActionRequest FilterWheel::adjustAction | ( | baci::BACIComponent * | cob_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchrnous adjust() method This is the function that moves the wheel of some steps and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void ErrorComponent::badMethod | ( | CORBA::Short | depth | ) | [virtual, inherited] |
Simple method raises a remote exception within the calling client. Implementation of IDL badMethod().
- Parameters:
-
depth depth of the error trace
- Exceptions:
-
ACSErrTypeCommon::GenericErrorEx ACSErrTypeCommon::UnexpectedExceptionEx
| virtual void HelloWorld::badMethod | ( | ) | [virtual, inherited] |
Simple method raises a remote exception within the calling client. Implementation of IDL badMethod().
- Exceptions:
-
ACSErrTypeCommon::UnknownEx
| virtual void InitErrorHelloWorld::badMethod | ( | ) | [virtual, inherited] |
Simple method raises a remote exception within the calling client. Implementation of IDL badMethod().
- Exceptions:
-
ACSErrTypeCommon::UnknownEx
| virtual void ConstrErrorHelloWorld::badMethod | ( | ) | [virtual, inherited] |
Simple method raises a remote exception within the calling client. Implementation of IDL badMethod().
- Exceptions:
-
ACSErrTypeCommon::UnknownEx
| virtual ACS::RWdouble_ptr Lamp::brightness | ( | ) | [virtual, inherited] |
Returns a reference to the Brightness property Implementation of IDL interface for the property.
| virtual void ErrorComponent::buildErrorTrace | ( | unsigned short | depth | ) | [private, virtual, inherited] |
The aim of this method is to build an error trace. It builds the error trace using exception, but the same could be done using Completion. It simply throw an exception containing an error trace with the requested depth, if > 0 Otherwise just returns.
Notice that this method throws a LOCAL exception xxxExImpl and not a remote exception xxx
- Parameters:
-
depth depth of the error trace
- Exceptions:
-
ACSErrTypeCommon::GenericErrorExImpl
| virtual CORBA::Long FilterWheel::calibrateFilter | ( | const char * | name | ) | [virtual, inherited] |
Calibrate the delta of the filter by reading the actual position and the step of the slot where the filter is mounted (it also updates the value in the CDB)
- Parameters:
-
name The name of the filter to calibrate
- Returns:
- The new delta for the filter
| virtual CORBA::Long FilterWheel::calibrateWheel | ( | int | slot | ) | [virtual, inherited] |
Calibrate the step for the slot by reading the actual position (it also updates the value in the CDB)
- Parameters:
-
slot The number of the slot to calibrate
- Returns:
- The new step for the slot
| static void LampWheel::char_hndl | ( | void * | data, | |
| const XML_Char * | s, | |||
| int | len | |||
| ) | [static, private, inherited] |
The handler for the char element
- See also:
- libexpat documentation for further info
| virtual void Door::checkSubstate | ( | CompletionImpl *& | error_p | ) | [private, virtual, inherited] |
Checks substate Checks for the device's substate. If the device is busy it returns an error. The purpose of this function is to show how to handle local error information.
- Parameters:
-
error completion return variable
- Returns:
- void
| virtual void FridgeControl::cleanUp | ( | ) | [virtual, inherited] |
Called after the last functional call to the component has finished. The component should then orderly release resources etc.
As required by the CharacteristicComponentImpl class, I call explicitly the cleanUp() of the parent class. This makes sure that all threads are stopped and the Component's state set. Depending on what resources are used by a class implementing a Component and by the implementation of the parent class (if it does not inherit directly from acscomponent::ACSComponentImpl or baci:: CharacteristicComponentImpl) it might be necessary to call the cleanuUp() method of the base class AFTER having released resources allocated by the current class. This is demonstrated in this example where we want to make sure that the powerStatus is FRIDGE::OFF before letting the cleanUp() of the base class stopping all the threads, including the one that regulates the temperature. For an example where the cleanUp() of the parent class is called before any other step, see the Building class. Always check the documentation of the parent class and consider what resources are allocated by this class to extablish the requirements for the execution of lifecycle chained methods.
- Returns:
- void
| virtual void Building::cleanUp | ( | ) | [virtual, inherited] |
Called after the last functional call to the component has finished. The component should then orderly release resources etc.
As required by the CharacteristicComponentImpl class, I call first explicitly the cleanUp() of the parent class. This makes sure that all threads are stopped and the Component's state set. Depending on what resources are used by a class implementing a Component and by the implementation of the parent class (if it does not inherit directly from acscomponent::ACSComponentImpl or baci:: CharacteristicComponentImpl) it might be necessary to call the cleanuUp() method of the base class AFTER having released resources allocated by the current class. For an example, see the FridgeControl class Always check the documentation of the parent class and consider what resources are allocated by this class to extablish the requirements for the execution of lifecycle chained methods.
- Returns:
- void
| virtual void LampWheel::cleanUp | ( | ) | [virtual, inherited] |
Called after the last functional call to the component has finished. The component should then orderly release resources etc. If this method is overwritten in a subclass, the developer has to make sure that all cleanup performed by the implementation of the base class take place. The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a destructor chain. If this method is overwritten in a chain of subclasses, the developer might need to make sure that all activities performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a destructor chain. In this class the default implementation only sets the state of the component to acscomponent::ACS::COMPSTATE_DESTROYING
- Returns:
- void
| virtual void FilterWheel::cleanUp | ( | ) | [virtual, inherited] |
Called after the last functional call to the component has finished. The component should then orderly release resources etc. If this method is overwritten in a subclass, the developer has to make sure that all cleanup performed by the implementation of the base class take place. The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a destructor chain. If this method is overwritten in a chain of subclasses, the developer might need to make sure that all activities performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a destructor chain. In this class the default implementation only sets the state of the component to acscomponent::ACS::COMPSTATE_DESTROYING
- Returns:
- void
| virtual void Door::close | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Closes the door Implementation of IDL close() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Door::closeAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb callback when action has finished desc callback used for holding information on timeout periods
- Returns:
- void
| virtual void FridgeControl::close | ( | ) | [virtual, inherited] |
Close the door.
- Returns:
- void
| virtual baci::ActionRequest Door::closeAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynch. close() method This is the function that actually closes the Door and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p owner of the action callbackID id of the callback to be notified descIn callback descriptor (passed by client) value action data (e.g., parameters to the original CORBA method) completion error handing structure descOut callback descriptor which will be passed to client
- Returns:
- request to be performed by BACI
- reqNone - do nothing (action will be kept in queue)
- reqInvokeWorking - invoke <type>Callback::working
- reqInvokeDone - invoke <type>Callback::done and destroy callback
- reqDestroy - destroy callback (callback should has been called already by function)
| virtual void Building::closeFrontDoor | ( | ) | [virtual, inherited] |
Closes the FRONTDOOR Implementation of the IDL closeFrontDoor() interface.
- Returns:
- void
| virtual ACS::ROdouble_ptr Mount::cmdAz | ( | ) | [virtual, inherited] |
Returns a reference to the cmdAz property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property cmdAz
| virtual ACS::ROdouble_ptr SlowMount::cmdAz | ( | ) | [virtual, inherited] |
Returns a reference to the cmdAz property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property cmdAz
| virtual ACS::ROdouble_ptr Mount::cmdEl | ( | ) | [virtual, inherited] |
Returns a reference to the cmdEl property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property cmdEl
| virtual ACS::ROdouble_ptr SlowMount::cmdEl | ( | ) | [virtual, inherited] |
Returns a reference to the cmdEl property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property cmdEl
| virtual ACSErr::Completion* ErrorComponent::completionFromCompletion | ( | CORBA::Short | depth | ) | [virtual, inherited] |
Simple method that returns a REMOTE (CORBA) completion (ACSErr::Completion), where an error trace is added from a completion.
- Parameters:
-
depth depth of the error trace, if <=0, returns OK completion
- Returns:
- ACSErr::Completion
| virtual ACSErr::Completion* ErrorComponent::completionFromException | ( | CORBA::Short | depth | ) | [virtual, inherited] |
Simple method that returns an ACSErr::Completion, where an error trace is added from an exception.
- Parameters:
-
depth depth of the error trace, if <=0, returns OK completion
- Returns:
- ACSErr::Completion
| ACSErr::Completion* ErrorComponent::completionOnStack | ( | CORBA::Short | depth | ) | [inherited] |
This method is similar than completionFromCompletion, but it allocated C++ completion on the stack instead on the heap.
- Parameters:
-
depth depth of the error trace, if <=0, returns OK completion
- Returns:
- ACSErr::Completion
| virtual void ErrorComponent::corbaSystemException | ( | ) | [virtual, inherited] |
Method that throws a CORBA::BAD_PARAM system exception to show how to handle CORBA System Exceptions
| virtual ACSErr::CompletionImpl* ErrorComponent::createCompletion | ( | unsigned short | depth | ) | [private, virtual, inherited] |
This method return a LOCAL (C++) completion which contains an error trace if depth > 0, otherwise it returns non error completion (ACSErrOKCompletion), i.e. completion w/o ane error trace
- Parameters:
-
depth depth of the error trace
| virtual ACS::RWdouble_ptr PowerSupply::current | ( | ) | [virtual, inherited] |
Returns a reference to the current_p property (commanded current). Implementation of IDL interface for the property.
- Returns:
- a pointer to the property
| virtual ACS::ROdouble_ptr FridgeControl::currTemperature | ( | ) | [virtual, inherited] |
Property currTemperature shows the fridge's actual temperature.
- Returns:
- Reference to the BACI property
| virtual ::acsexmplCalendar::RWDaysEnum_ptr Calendar::day | ( | ) | [inherited] |
Returns a reference to the day property Implementation of IDL interface for the property.
| virtual ACS::ROstring_ptr FilterWheel::desc | ( | ) | [virtual, inherited] |
Returns a reference to the desc property Implementation of IDL interface for the property.
| virtual ACS::ROstring_ptr LampWheel::desc | ( | ) | [virtual, inherited] |
Returns a reference to the desc property Implementation of IDL interface for the property.
| virtual void ConstrErrorHelloWorld::displayMessage | ( | ) | [virtual, inherited] |
Displays "Hello World" to the console. Implementation of IDL displayMessage().
| virtual void ErrorComponent::displayMessage | ( | ) | [virtual, inherited] |
Displays "Hello World" to the console. Implementation of IDL displayMessage().
| virtual void HelloWorld::displayMessage | ( | ) | [virtual, inherited] |
Displays "Hello World" to the console. Implementation of IDL displayMessage().
| virtual void InitErrorHelloWorld::displayMessage | ( | ) | [virtual, inherited] |
Displays "Hello World" to the console. Implementation of IDL displayMessage().
| Door::Door | ( | const ACE_CString & | name, | |
| maci::ContainerServices * | containerServices | |||
| ) | [inherited] |
Constructor
- Parameters:
-
poa poa which will activate this and also all other components name component name
| virtual FRIDGE::ROOpClStates_ptr FridgeControl::doorStatus | ( | ) | [virtual, inherited] |
Property doorStatus shows the position of the door.
- Returns:
- Reference to the BACI property
| static void LampWheel::end_hndl | ( | void * | data, | |
| const XML_Char * | el | |||
| ) | [static, private, inherited] |
The handler for the end element
- See also:
- libexpat documentation for further info
| virtual void ErrorComponent::exceptionFromCompletion | ( | CORBA::Short | depth | ) | [virtual, inherited] |
Simple method raises a remote exception within the calling client. The error trace in the exception is added from a completion. Implementation of IDL method.
- Parameters:
-
depth depth of the error trace
- Exceptions:
-
ACSErrTypeCommon::GenericErrorEx
| virtual void Door::execute | ( | ) | [virtual, inherited] |
Called after initialize to tell the component that it has to be ready to accept incoming functional calls any time. Must be implemented as a synchronous (blocking) call (can spawn threads though).
- Exceptions:
-
ACSErr::ACSbaseExImpl
- Returns:
- void
| virtual void PowerSupply::execute | ( | ) | [virtual, inherited] |
Called after initialize to tell the component that it has to be ready to accept incoming functional calls any time. Must be implemented as a synchronous (blocking) call (can spawn threads though).
- Returns:
- void
- Exceptions:
-
ACSErr::ACSbaseExImpl
| virtual void Building::execute | ( | ) | [virtual, inherited] |
Called after initialize to tell the component that it has to be ready to accept incoming functional calls any time. Must be implemented as a synchronous (blocking) call (can spawn threads though).
- Exceptions:
-
ACSErr::ACSbaseExImpl
- Returns:
- void
| virtual void AmsTestSeq::execute | ( | ) | [virtual, inherited] |
Called after initialize to tell the component that it has to be ready to accept incoming functional calls any time. Must be implemented as a synchronous (blocking) call (can spawn threads though).
- Exceptions:
-
ACSErr::ACSbaseExImpl
- Returns:
- void
| virtual void LampWheel::execute | ( | ) | [virtual, inherited] |
Called after initialize to tell the component that it has to be ready to accept incoming functional calls any time. Must be implemented as a synchronous (blocking) call (can spawn threads though). If this method is overwritten in a chain of subclasses, the developer might need to make sure that all activities performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a constructor chain. In this class the default implementation only sets the state of the component to acscomponent::ACS::COMPSTATE_OPERATIONAL
- Returns:
- void
- Exceptions:
-
ACSErr::ACSbaseExImpl
| virtual void FilterWheel::execute | ( | ) | [virtual, inherited] |
Called after initialize to tell the component that it has to be ready to accept incoming functional calls any time. Must be implemented as a synchronous (blocking) call (can spawn threads though). If this method is overwritten in a chain of subclasses, the developer might need to make sure that all activities performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a constructor chain. In this class the default implementation only sets the state of the component to acscomponent::ACS::COMPSTATE_OPERATIONAL
- Exceptions:
-
ACSErr::ACSbaseExImpl
- Returns:
- void
| void ErrorComponent::generateSIGFPE | ( | CORBA::Short | way | ) | [inherited] |
A method wich will generate the SIGFPE signal This can be used to test what happens when there is a floating point exception in a component
- Parameters:
-
way parameter used to specify the way to generate the SIGFPE way == 0: Send SIGFPE signal with the kill() function363 way == 1: Generate a floating point exception by dividing by 0
| void ErrorComponent::generateSIGSEGV | ( | CORBA::Short | way | ) | [inherited] |
A method wich will generate the SIGSEGV signal This can be used to test what happens when there is a segmentation fault in a component
- Parameters:
-
way parameter used to specify the way to generate the SIGSEGV way == 0: Send SIGSEGV signal with the kill() function way == 1: Generate a segmentation fault by accessing to a null pointer
| virtual void InitErrorHelloWorld::initialize | ( | ) | [virtual, inherited] |
This method in the example will throw an exception. The goal here is to be able to test the behaviour of ACS when a component throw an exception during the initialization.
- Returns:
- void
- Exceptions:
-
ACSErr::ACSbaseExImpl
Reimplemented from acscomponent::ACSComponentImpl.
| virtual void LampWheel::initialize | ( | ) | [virtual, inherited] |
Called to give the component time to initialize itself. For instance, the component could retrieve connections, read in configuration files/parameters, build up in-memory tables, ... Called before execute. In fact, this method might be called quite some time before functional requests can be sent to the component. Must be implemented as a synchronous (blocking) call. If this method is overwritten in a chain of subclasses, the developer has to make sure that all initialisations performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). If necessary, the best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a constructor chain. In this class the default implementation only sets the state of the component first to acscomponent::ACS::COMPSTATE_INITIALIZING and then to acscomponent::ACS::COMPSTATE_INITIALIZED.
- Returns:
- void
- Exceptions:
-
ACSErr::ACSbaseExImpl
| virtual void FilterWheel::initialize | ( | ) | [virtual, inherited] |
Called to give the component time to initialize itself. For instance, the component could retrieve connections, read in configuration files/parameters, build up in-memory tables, ... Called before execute. In fact, this method might be called quite some time before functional requests can be sent to the component. Must be implemented as a synchronous (blocking) call. If this method is overwritten in a chain of subclasses, the developer has to make sure that all initialisations performed by the implementation of the base class take place. Check the documentation of direct parent class to know if this is necessary (and do not forget to document each class for the need to chain lifecycle methods in subclasses). If necessary, the best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a constructor chain. In this class the default implementation only sets the state of the component first to acscomponent::ACS::COMPSTATE_INITIALIZING and then to acscomponent::ACS::COMPSTATE_INITIALIZED.
- Parameters:
-
containerServices pointer to services provided by the container
- Exceptions:
-
ACSErr::ACSbaseExImpl
- Returns:
- void
| virtual baci::ActionRequest PowerSupply::invokeAction | ( | int | function, | |
| baci::BACIComponent * | component_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function action funtion to be invoked component_p owner of the action callbackID id of the callback to be notified descIn callback descriptor (passed by client) value_p action data (e.g. value to be set) completion error handing structure descOut callback descriptor which will be passed to client
- Returns:
- request to be performed by baci::BACI
- reqNone - do nothing (action will be kept in queue)
- reqInvokeWorking - invoke <type>Callback::working
- reqInvokeDone - invoke <type>Callback::done and destroy callback
- reqDestroy - destroy callback (callback should has been called already by function)
Implements baci::ActionImplementator.
Reimplemented in RampedPowerSupply.
| virtual baci::ActionRequest RampedPowerSupply::invokeAction | ( | int | function, | |
| baci::BACIComponent * | component_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function action funtion to be invoked component_p owner of the action callbackID id of the callback to be notified descIn callback descriptor (passed by client) value_p action data (e.g. value to be set) completion error handing structure descOut callback descriptor which will be passed to client
- Returns:
- request to be performed by BACI
- reqNone - do nothing (action will be kept in queue)
- reqInvokeWorking - invoke <type>Callback::working
- reqInvokeDone - invoke <type>Callback::done and destroy callback
- reqDestroy - destroy callback (callback should has been called already by function)
Reimplemented from PowerSupply.
| virtual baci::ActionRequest SlowMount::invokeAction | ( | int | function, | |
| baci::BACIComponent * | component_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function Action funtion to be invoked. component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should have been called already by function).
Implements baci::ActionImplementator.
| virtual baci::ActionRequest Lamp::invokeAction | ( | int | function, | |
| baci::BACIComponent * | cob_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function Action funtion to be invoked. cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should have been called already by function).
Implements baci::ActionImplementator.
| virtual baci::ActionRequest Door::invokeAction | ( | int | function, | |
| baci::BACIComponent * | component_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function action funtion to be invoked component_p owner of the action callbackID id of the callback to be notified descIn callback descriptor (passed by client) value_p action data (e.g., parameters to the original CORBA method) completion error handing structure descOut callback descriptor which will be passed to client
- Returns:
- request to be performed by BACI
- reqNone - do nothing (action will be kept in queue)
- reqInvokeWorking - invoke <type>Callback::working
- reqInvokeDone - invoke <type>Callback::done and destroy callback
- reqDestroy - destroy callback (callback should has been called already by function)
Implements baci::ActionImplementator.
| virtual baci::ActionRequest LampWheel::invokeAction | ( | int | function, | |
| baci::BACIComponent * | cob_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function Action funtion to be invoked. cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should have been called already by function).
Implements baci::ActionImplementator.
| virtual baci::ActionRequest FilterWheel::invokeAction | ( | int | function, | |
| baci::BACIComponent * | cob_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function Action funtion to be invoked. cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should have been called already by function).
Implements baci::ActionImplementator.
| virtual baci::ActionRequest Mount::invokeAction | ( | int | function, | |
| baci::BACIComponent * | component_p, | |||
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Action dispatcher function This function is called whenever an asynchronous request has to be handled. It receives (as parameters) the description of the function and selects the proper implementation to call.
- Parameters:
-
function Action funtion to be invoked. component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should have been called already by function).
Implements baci::ActionImplementator.
| virtual void FridgeControl::loadData | ( | ) | [private, virtual, inherited] |
Converts this devices useful data into a temperatureDataBlockEvent structure and then publishes that onto an event channel.
- Returns:
- void
| virtual ::acsexmplCalendar::RWMonthEnum_ptr Calendar::month | ( | ) | [inherited] |
Returns a reference to the month property Implementation of IDL interface for the property.
| virtual void Door::move | ( | CORBA::Double | pos | ) | [virtual, inherited] |
Moves the door to the given position Implementation of the IDL move(...) interface. This method, while synchronous, only changes the reference position (i.e., m_ref_position_p) while DoorThread actually handles the change in the door position via an ACS thread.
- Parameters:
-
pos requested position - must be between 0 and a 100.
- Returns:
- void
| virtual void LampWheel::move | ( | CORBA::Short | , | |
| ACS::CBvoid_ptr | , | |||
| const ACS::CBDescIn & | ||||
| ) | [virtual, inherited] |
Move the lamp wheel to a specification slot. The position of the slot is read from the database Implementation of IDL move(...) interface. The actual action will be invoked asyncronously by the asynchonous call manager by calling LampWhell::moveAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
n The number of the slot to move to callBack Callback when action has finished. desc Callback used for holding information on timeout periods.
| virtual baci::ActionRequest LampWheel::moveAction | ( | baci::BACIComponent * | cob_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchrnous acsexmplLamp::Lamp::off() method This is the function that actually switches off the Lamp and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual baci::ActionRequest FilterWheel::moveFilterAction | ( | baci::BACIComponent * | cob_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchrnous moveFilterInBeam method This is the function that actually rotate the wheel to the slot of the selected filter (it also take in account the per-filter adjustament represented by the delta filed in the description of the filter in the CDB) When completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void FilterWheel::moveFilterInBeam | ( | const char * | , | |
| ACS::CBvoid_ptr | , | |||
| const ACS::CBDescIn & | ||||
| ) | [virtual, inherited] |
Move the filter wheel to a specification slot. Implementation of IDL moveFilterInBeam(...) interface. The actual action will be invoked asyncronously by the asynchonous call manager by calling LampWhell::moveAction The given callback is used to inform the caller when the action is performed.
| virtual baci::ActionRequest FilterWheel::moveSlotAction | ( | baci::BACIComponent * | cob_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchrnous moveSlotInBeam method This is the function that actually rotate the wheel to the selected slot When completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void FilterWheel::moveSlotInBeam | ( | int | , | |
| ACS::CBvoid_ptr | , | |||
| const ACS::CBDescIn & | ||||
| ) | [virtual, inherited] |
Move the filter wheel to a specific slot. Implementation of IDL moveSlotInBeam(...) interface. The actual action will be invoked asyncronously by the asynchonous call manager by calling LampWhell::moveAction The given callback is used to inform the caller when the action is performed.
| virtual void Mount::objfix | ( | CORBA::Double | az, | |
| CORBA::Double | elev, | |||
| ACS::CBvoid_ptr | callBack, | |||
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation. The actual az and elev values are written to the properties cmdAz, cmdEl, actAz and actEl.
This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Mount::objfixAction(...). The given callback is used to inform the caller when the action is performed.
- Parameters:
-
az position azimuth (degree) elev position elevation (degree) callBack Callback when action has finished. desc Callback used for holding information on timeout periods
- Returns:
- void
| virtual void SlowMount::objfix | ( | CORBA::Double | az, | |
| CORBA::Double | elev, | |||
| ACS::CBvoid_ptr | callBack, | |||
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation. The actual az and elev values are written to the properties cmdAz, cmdEl, actAz and actEl.
This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Mount::objfixAction(...). The given callback is used to inform the caller when the action is performed.
- Parameters:
-
az position azimuth (degree) elev position elevation (degree) callBack Callback when action has finished. desc Callback used for holding information on timeout periods
- Returns:
- void
| virtual baci::ActionRequest SlowMount::objfixAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchronous MOUNT_ACS::Mount::objfix() method This is the function that actually runs objfix(...) and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual baci::ActionRequest Mount::objfixAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchronous MOUNT_ACS::Mount::objfix() method This is the function that actually runs objfix(...) and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void SlowMount::obstar | ( | CORBA::Double | ra, | |
| CORBA::Double | dec, | |||
| CORBA::Double | pmRa, | |||
| CORBA::Double | pmDec, | |||
| CORBA::Double | radVel, | |||
| CORBA::Double | par, | |||
| MOUNT_ACS::Mount::coordType | type, | |||
| ACS::CBvoid_ptr | callBack, | |||
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
(Pre)sets a new equatorial source for the antenna to track. The source position is given in geocentric equatorial J2000 coordinates. The actual ra and dec coordinates are written to the properties cmdAz, cmdEl, actAz and actEl.
This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Mount::obstarAction(...). The given callback is used to inform the caller when the action is performed.
- Parameters:
-
ra source right ascension (hour) dec source declination (hour) pmRa source sky proper motion in right ascension (arc-sec/year) pmDec source sky proper motion in declination (arc-sec/year) radVel source radial velocity (kilometer/sec) par source parallax correction (arc-sec) type Apparent or Mean callBack Callback when action has finished. desc Callback used for holding information on timeout periods
- Returns:
- void
| virtual void Mount::obstar | ( | CORBA::Double | ra, | |
| CORBA::Double | dec, | |||
| CORBA::Double | pmRa, | |||
| CORBA::Double | pmDec, | |||
| CORBA::Double | radVel, | |||
| CORBA::Double | par, | |||
| MOUNT_ACS::Mount::coordType | type, | |||
| ACS::CBvoid_ptr | callBack, | |||
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
(Pre)sets a new equatorial source for the antenna to track. The source position is given in geocentric equatorial J2000 coordinates. The actual ra and dec coordinates are written to the properties cmdAz, cmdEl, actAz and actEl.
This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Mount::obstarAction(...). The given callback is used to inform the caller when the action is performed.
- Parameters:
-
ra source right ascension (hour) dec source declination (hour) pmRa source sky proper motion in right ascension (arc-sec/year) pmDec source sky proper motion in declination (arc-sec/year) radVel source radial velocity (kilometer/sec) par source parallax correction (arc-sec) type Apparent or Mean callBack Callback when action has finished. desc Callback used for holding information on timeout periods
- Returns:
- void
| virtual baci::ActionRequest SlowMount::obstarAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchronous MOUNT_ACS::Mount::obstar() method This is the function that actually runs obstar(...) and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual baci::ActionRequest Mount::obstarAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchronous MOUNT_ACS::Mount::obstar() method This is the function that actually runs obstar(...) and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void PowerSupply::off | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Switches off the power supply. Implementation of IDL off() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling PowerSupply::offAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb Callback when action has finished. desc Callback used for holding information on timeout periods
| virtual void FridgeControl::off | ( | ) | [virtual, inherited] |
Turn off the fridge.
- Returns:
- void
| virtual void Lamp::off | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Switches off the lamp. Implementation of IDL off() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Lamp::offAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
callBack Callback when action has finished. desc Callback used for holding information on timeout periods.
| virtual baci::ActionRequest PowerSupply::offAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of async. off() method This is the function that actually switches off the PowerSupply and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by baci::BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual baci::ActionRequest Lamp::offAction | ( | baci::BACIComponent * | cob_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchrnous acsexmplLamp::Lamp::off() method This is the function that actually switches off the Lamp and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void PowerSupply::on | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Switches on the power supply. Implementation of IDL on() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling PowerSupply::onAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb Callback when action has finished. desc Callback used for holding information on timeout periods
| virtual void FridgeControl::on | ( | ) | [virtual, inherited] |
Turn on the fridge.
- Returns:
- void
| virtual void Lamp::on | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Switches on the lamp. Implementation of IDL on() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Lamp::onAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
callBack Callback when action has finished. desc Callback used for holding information on timeout periods
| virtual baci::ActionRequest PowerSupply::onAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of async. on() method This is the function that actually switches on the PowerSupply and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by baci::BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual baci::ActionRequest Lamp::onAction | ( | baci::BACIComponent * | cob_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynchronous acsexmplLamp::Lamp::on() method This is the function that actually switches on the Lamp and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
cob Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual void DoorThread::onStart | ( | ) | [virtual, inherited] |
Method which is executed before the body of the thread. It is the hook method for a user that wants to do some initialization before the thread execution (thread initialization), s/he has to override/implement this method in the implementation class. It is called by commonStart
Reimplemented from ACS::Thread.
| virtual void DoorThread::onStop | ( | ) | [virtual, inherited] |
Method which is executed after the body of the thread, i.e. after the thread execution. It is the hook method for a user that wants to do some cleanup after the thread execution (thread cleanup), s/he has to override/implement this method in the implementation class. It is called by commonStop
Reimplemented from ACS::Thread.
| virtual void Door::open | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Opens the door Implementation of IDL open() interface. This method just registers the request in the asyncronous queue together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling Door::openAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb callback when action has finished desc callback used for holding information on timeout periods
- Returns:
- void
| virtual void FridgeControl::open | ( | ) | [virtual, inherited] |
Open the door.
- Returns:
- void
| virtual baci::ActionRequest Door::openAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of asynch. open() method This is the function that actually opens the Door and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p owner of the action callbackID id of the callback to be notified descIn callback descriptor (passed by client) value_p action data (e.g., parameters to the original CORBA method) completion error handing structure descOut callback descriptor which will be passed to client
- Returns:
- request to be performed by BACI
- reqNone - do nothing (action will be kept in queue)
- reqInvokeWorking - invoke <type>Callback::working
- reqInvokeDone - invoke <type>Callback::done and destroy callback
- reqDestroy - destroy callback (callback should has been called already by function)
| virtual void Building::openFrontDoor | ( | ) | [virtual, inherited] |
Opens the FRONTDOOR Implementation of the IDL openFrontDoor() interface.
- Returns:
- void
| void PowerSupply::operator= | ( | const PowerSupply & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void FilterWheel::operator= | ( | const FilterWheel & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void Calendar::operator= | ( | const Calendar & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void Door::operator= | ( | const Door & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void Lamp::operator= | ( | const Lamp & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void FridgeControl::operator= | ( | const FridgeControl & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void AmsTestSeq::operator= | ( | const AmsTestSeq & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void Building::operator= | ( | const Building & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void RampedPowerSupply::operator= | ( | const RampedPowerSupply & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void SlowMount::operator= | ( | const SlowMount & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void Mount::operator= | ( | const Mount & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void LampWheel::operator= | ( | const LampWheel & | ) | [private, inherited] |
ALMA C++ coding standards state copy operators should be disabled.
| void ErrorComponent::outCompletion | ( | ACSErr::Completion_out | comp | ) | [inherited] |
Simple method that returns an ACSErr::Completion as an out parameter
- Parameters:
-
comp Completion as out parameter
| virtual ACS::ROdouble_ptr FilterWheel::position | ( | ) | [virtual, inherited] |
Returns a reference to the position property Implementation of IDL interface for the property.
| virtual ACS::ROdouble_ptr Door::position | ( | ) | [virtual, inherited] |
Property for readback m_position_p Implementation of IDL interface for the property.
- Returns:
- Read-only double pointer to the door's current position
| virtual ACS::ROdouble_ptr LampWheel::position | ( | ) | [virtual, inherited] |
Returns a reference to the position property Implementation of IDL interface for the property.
| virtual FRIDGE::ROOnOffStates_ptr FridgeControl::powerStatus | ( | ) | [virtual, inherited] |
Property powerStatus shows whether the power is on or off.
- Returns:
- Reference to the BACI property
| virtual ACS::RWstring_ptr RampedPowerSupply::rampingStatus | ( | ) | [virtual, inherited] |
Returns a reference to the rampingStatus property (status). Implementation of IDL interface for the property.
- Returns:
- a pointer to the BACI property
| virtual ACS::ROlong_ptr RampedPowerSupply::rampingStep | ( | ) | [virtual, inherited] |
Returns a reference to the rampingStep property. Implementation of IDL interface for the property.
- Returns:
- a pointer to the BACI property
| virtual ACS::ROdouble_ptr PowerSupply::readback | ( | ) | [virtual, inherited] |
Returns a reference to the readback_p property (actual current). Implementation of IDL interface for the property.
- Returns:
- a pointer to the property
| void FilterWheel::readConfiguration | ( | Descriptor * | descr | ) | [private, inherited] |
Read the CDB to build the actual configuration of the wheel
- Parameters:
-
descr The list of descriptor describing the actual configuration of the wheel
| virtual ACS::RWdouble_ptr Door::ref_position | ( | ) | [virtual, inherited] |
Property for reference position Implementation of IDL interface for the property.
- Returns:
- Read/write double pointer to where the door should be physically located
| virtual ACS::RWdouble_ptr FridgeControl::refTemperature | ( | ) | [virtual, inherited] |
Property refTemperature is like a thermostat for the fridge.
- Returns:
- Reference to the BACI property
| virtual void PowerSupply::reset | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Resets the power supply. Implementation of IDL reset() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling PowerSupply::resetAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb Callback when action has finished. desc Callback used for holding information on timeout periods
| virtual baci::ActionRequest PowerSupply::resetAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of async. reset() method This is the function that actually resets the PowerSupply and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| int LampWheel::retrieveConfigurationFromCDB | ( | std::list< SlotDescriptor > & | config | ) | [private, inherited] |
Read the CDB and fill the list with the actual configuration of each slot
- Parameters:
-
config The list describing the configuration
- Returns:
- The number of slots found in the CDB
| virtual ACS::ROdoubleSeq_ptr AmsTestSeq::ROdoubleSeqPM | ( | ) | [virtual, inherited] |
Returns a reference to the ROdoubleSeqPM property Implementation of IDL interface for the property.
| virtual void DoorThread::runLoop | ( | ) | [virtual, inherited] |
Basic used hook to implement the thread functionality in a periodic loop. The method is executed in a loop until the thread is alive and every responseTime 100ns by the run method. The thread can be exited from the lop by calling ACS::ThreadBase::stop or ACS::ThreadBase::exit command. If the run method is overridden than runLoop is not executed.
Reimplemented from ACS::Thread.
| virtual void FridgeThread::runLoop | ( | ) | [virtual, inherited] |
Basic used hook to implement the thread functionality in a periodic loop. The method is executed in a loop until the thread is alive and every responseTime 100ns by the run method. The thread can be exited from the lop by calling ACS::ThreadBase::stop or ACS::ThreadBase::exit command. If the run method is overridden than runLoop is not executed.
Reimplemented from ACS::Thread.
| virtual ACS::RWdoubleSeq_ptr AmsTestSeq::RWdoubleSeqPM | ( | ) | [virtual, inherited] |
Returns a reference to the RWdoubleSeqPM property Implementation of IDL interface for the property.
| virtual void AmsTestSeq::setCoeff | ( | ) | [virtual, inherited] |
Sets the coefficients of the pointing model.
- Returns:
- void
| void ErrorComponent::sleepingCmd | ( | CORBA::Short | nb_seconds | ) | [inherited] |
A method that will sleep during nb_seconds seconds before to return This method could be used to test the behavior of components taking a long time before to reply.
- Parameters:
-
nb_seconds the number of seconds to sleep before to return
| virtual ACS::ROlong_ptr FilterWheel::slots | ( | ) | [virtual, inherited] |
Returns a reference to the descavailableSlots property Implementation of IDL interface for the property.
| virtual ACS::ROlong_ptr LampWheel::slots | ( | ) | [virtual, inherited] |
Returns a reference to the descavailableSlots property Implementation of IDL interface for the property.
| static void LampWheel::start_hndl | ( | void * | data, | |
| const XML_Char * | el, | |||
| const XML_Char ** | attr | |||
| ) | [static, private, inherited] |
The handler for the start element
- See also:
- libexpat documentation for further info
| virtual void RampedPowerSupply::startRamping | ( | CORBA::Long | rampingSteps, | |
| ACS::CBvoid_ptr | cb, | |||
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Starts ramping the power supply. Implementation of IDL startRamping() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling RampedPowerSupply::startRampingAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb Callback when action has finished. desc Callback used for holding information on timeout periods
| virtual baci::ActionRequest RampedPowerSupply::startRampingAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of async. startRamping() method This is the function that actually starts ramping and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual ::acsexmplCalendar::ROStateEnum_ptr Calendar::state | ( | ) | [inherited] |
Returns a reference to the state property Implementation of IDL interface for the property.
| virtual ACS::ROpattern_ptr PowerSupply::status | ( | ) | [virtual, inherited] |
Returns a reference to the status_p property (see acsexmplPowerSupplyImpl.cpp). Implementation of IDL interface for the property.
- Returns:
- a pointer to the property
| virtual void RampedPowerSupply::stopRamping | ( | ACS::CBvoid_ptr | cb, | |
| const ACS::CBDescIn & | desc | |||
| ) | [virtual, inherited] |
Stops ramping the power supply. Implementation of IDL stopRamping() interface. This method just registers the request in the asyncronous queue, together with the associated callback and returns control immediatly. The actual action will be invoked asyncronously by the asynchonous call manager by calling RampedPowerSupply::stopAction The given callback is used to inform the caller when the action is performed.
- Parameters:
-
cb Callback when action has finished. desc Callback used for holding information on timeout periods
| virtual baci::ActionRequest RampedPowerSupply::stopRampingAction | ( | baci::BACIComponent * | component_p, | |
| const int & | callbackID, | |||
| const CBDescIn & | descIn, | |||
| baci::BACIValue * | value_p, | |||
| Completion & | completion, | |||
| CBDescOut & | descOut | |||
| ) | [virtual, inherited] |
Implementation of async. stopRamping() method This is the function that actually stops ramping and, when completed, invokes the callback installed by the client when it requested the action.
- Parameters:
-
component_p Owner of the action. callbackID ID of the callback to be notified. descIn Callback descriptor (passed by client). value_p Action data (e.g. value to be set). completion Error handing structure. descOut Callback descriptor which will be passed to client.
- Returns:
- Request to be performed by BACI.
- reqNone - Do nothing (action will be kept in queue).
- reqInvokeWorking - Invoke <type>Callback::working.
- reqInvokeDone - Invoke <type>Callback::done and destroy callback.
- reqDestroy - Destroy callback (callback should has been called already by function).
| virtual ACS::ROlong_ptr Door::substate | ( | ) | [virtual, inherited] |
Property for substate Implementation of IDL interface for the property.
- Returns:
- Read-only long integer pointer to the door's present state
| virtual void ErrorComponent::typeException | ( | CORBA::Short | depth | ) | [virtual, inherited] |
This method throws a REMOTE (CORBA) type exception if depth>0. If we want to throw a type exception we have to specfy this in the method signature. In this example the method can throw: ACSErrTypeCommon::GenericErrorEx or ACSErrTypeCommon::ACSErrTypeCommonEx exceptions. Although GenericErrorEx derives from ACSErrTypeCommonEx we have to specfy both in the method signature because IDL does not support hierarchy of exceptions.
- Parameters:
-
depth depth of the error trace
- Exceptions:
-
ACSErrTypeCommon::GenericErrorEx ACSErrTypeCommon::ACSErrTypeCommonEx
| void FilterWheel::updateFilter | ( | ACE_CString | name, | |
| int | delta | |||
| ) | [private, inherited] |
Permanently write the new delta for the given filter in the CDB
- Parameters:
-
name The name of the filter delta The new offset for the filter
| void FridgeControl::updateTemperature | ( | ) | [inherited] |
Updates the temperature from the physical device
- Returns:
- void
| void FilterWheel::updateWheel | ( | int | slot, | |
| int | step | |||
| ) | [private, inherited] |
Permanently write the new position for the given slot in the CDB
- Parameters:
-
slot,: The number of the slot to update step,: the new position of the slot
| virtual ACS::ROstring_ptr Building::version | ( | ) | [virtual, inherited] |
Returns a reference to the version property Implementation of IDL interface for the property.
- Returns:
- A pointer to the string containing the version number
| virtual ACS::ROstring_ptr Door::version | ( | ) | [virtual, inherited] |
Property for version Implementation of IDL interface for the property.
- Returns:
- Read-only string pointer to the door implementation's version
| virtual ::ACS::RWpattern_ptr Calendar::yearAttributes | ( | ) | [inherited] |
Returns a reference to the yearAttributes property Implementation of IDL interface for the property.
| virtual AmsTestSeq::~AmsTestSeq | ( | ) | [virtual, inherited] |
Destructor
| virtual Building::~Building | ( | ) | [virtual, inherited] |
Destructor
| virtual Calendar::~Calendar | ( | ) | [virtual, inherited] |
Destructor
| virtual ConstrErrorHelloWorld::~ConstrErrorHelloWorld | ( | ) | [virtual, inherited] |
Destructor
| virtual Door::~Door | ( | ) | [virtual, inherited] |
Destructor
| DoorThread::~DoorThread | ( | ) | [inline, inherited] |
References ACS_TRACE.
| virtual ErrorComponent::~ErrorComponent | ( | ) | [virtual, inherited] |
Destructor
| virtual FilterWheel::~FilterWheel | ( | ) | [virtual, inherited] |
Destructor
| virtual FridgeControl::~FridgeControl | ( | ) | [virtual, inherited] |
Destructor
| FridgeThread::~FridgeThread | ( | ) | [inline, inherited] |
References ACS_TRACE.
| virtual HelloWorld::~HelloWorld | ( | ) | [virtual, inherited] |
Destructor
| virtual InitErrorHelloWorld::~InitErrorHelloWorld | ( | ) | [virtual, inherited] |
Destructor
| virtual Lamp::~Lamp | ( | ) | [virtual, inherited] |
Destructor
| virtual LampWheel::~LampWheel | ( | ) | [virtual, inherited] |
Destructor
| virtual Mount::~Mount | ( | ) | [virtual, inherited] |
Destructor
| virtual PowerSupply::~PowerSupply | ( | ) | [virtual, inherited] |
Destructor
| RampedPowerSupply::~RampedPowerSupply | ( | ) | [inherited] |
Destructor
| virtual SlowMount::~SlowMount | ( | ) | [virtual, inherited] |
Destructor
Variable Documentation
int Descriptor::delta [inherited] |
Door* DoorThread::door_p [private, inherited] |
Referenced by DoorThread::DoorThread().
char Descriptor::filterName[128] [inherited] |
FridgeControl* FridgeThread::fridgeControl_p [protected, inherited] |
Referenced by FridgeThread::FridgeThread().
char SlotDescriptor::lampName[128] [inherited] |
int FridgeThread::loopCounter_m [protected, inherited] |
Referenced by FridgeThread::FridgeThread().
baci::SmartPropertyPointer<baci::ROdouble> Mount::m_actAz_sp [private, inherited] |
m_actAz_sp is the antenna's actual azimuth
baci::SmartPropertyPointer<baci::ROdouble> SlowMount::m_actAz_sp [private, inherited] |
m_actAz_sp is the antenna's actual azimuth
baci::SmartPropertyPointer<baci::ROdouble> Mount::m_actEl_sp [private, inherited] |
m_actEl_sp is the antenna's actual elevation
baci::SmartPropertyPointer<baci::ROdouble> SlowMount::m_actEl_sp [private, inherited] |
m_actEl_sp is the antenna's actual elevation
ActionFunction Mount::m_actions[2] [private, inherited] |
Please see ActionFunction. m_actions[0] = obstarAction(...) m_actions[1] = objfixAction(...)
ActionFunction SlowMount::m_actions[2] [private, inherited] |
Please see ActionFunction. m_actions[0] = obstarAction(...) m_actions[1] = objfixAction(...)
baci::SmartPropertyPointer<baci::RWdouble> Lamp::m_brightness_sp [private, inherited] |
m_brightness_sp is the lamp's setable brightness.
baci::SmartPropertyPointer<baci::ROdouble> Mount::m_cmdAz_sp [private, inherited] |
m_cmdAz_sp is the antenna's commanded azimuth
baci::SmartPropertyPointer<baci::ROdouble> SlowMount::m_cmdAz_sp [private, inherited] |
m_cmdAz_sp is the antenna's commanded azimuth
baci::SmartPropertyPointer<baci::ROdouble> Mount::m_cmdEl_sp [private, inherited] |
m_cmdEl_sp is the antenna's commanded elevation
baci::SmartPropertyPointer<baci::ROdouble> SlowMount::m_cmdEl_sp [private, inherited] |
m_cmdEl_sp is the antenna's commanded elevation
FridgeThread* FridgeControl::m_controlLoop_p [private, inherited] |
m_controlLoop_p is only started once the fridge has been turned on(). This thread is used to simulate the fridge's temperature trying to reach equillibrium with the reference temperature. Once the fridge has been turned off(), this thread is suspended.
baci::SmartPropertyPointer<PowerSupplyCurrent> PowerSupply::m_current_sp [private, inherited] |
m_current_sp is the commanded current.
baci::SmartPropertyPointer<baci::ROdouble> FridgeControl::m_currTemperature_sp [private, inherited] |
m_currTemperature_p is the temperature the fridge actually is.
baci::SmartPropertyPointer< RWEnumImpl<ACS_ENUM_T(acsexmplCalendar::DaysEnum), POA_acsexmplCalendar::RWDaysEnum> > Calendar::m_day_sp [private, inherited] |
m_day_sp represents the day of the year.
baci::SmartPropertyPointer<baci::ROstring> FilterWheel::m_desc_sp [private, inherited] |
m_desc_sp is the description of the wheel.
baci::SmartPropertyPointer<baci::ROstring> LampWheel::m_desc_sp [private, inherited] |
m_desc_sp is the description of the wheel.
acsexmplBuilding::Door_var Building::m_door_p [private, inherited] |
The door that belongs to this building.
baci::SmartPropertyPointer< ROEnumImpl<ACS_ENUM_T(FRIDGE::OpClStates), POA_FRIDGE::ROOpClStates> > FridgeControl::m_doorStatus_sp [private, inherited] |
The fridge's door can be either opened or closed.
DoorThread* Door::m_doorThread_p [private, inherited] |
nc::SimpleSupplier* FridgeControl::m_FridgeSupplier_p [private, inherited] |
This is the Supplier derived class used to publish data to the event channel.
ACE_CString FilterWheel::m_fullName [private, inherited] |
ACE_CString LampWheel::m_fullName [private, inherited] |
std::list<SlotDescriptor> LampWheel::m_lampWheelConfiguration [private, inherited] |
The list of descriptions of each slot of the wheel: it is the configuration of the lampWheel It is built reading the CDB
baci::SmartPropertyPointer< RWEnumImpl<ACS_ENUM_T(acsexmplCalendar::MonthEnum), POA_acsexmplCalendar::RWMonthEnum> > Calendar::m_month_sp [private, inherited] |
m_month_sp represents the month of the year.
baci::SmartPropertyPointer<baci::ROdouble> LampWheel::m_position_sp [private, inherited] |
m_position_sp is the position of the wheel.
baci::SmartPropertyPointer<baci::ROdouble> FilterWheel::m_position_sp [private, inherited] |
m_position_sp is the position of the wheel.
baci::SmartPropertyPointer<baci::ROdouble> Door::m_position_sp [private, inherited] |
m_position_sp is the Door's actual position
baci::SmartPropertyPointer<ROEnumImpl< ACS_ENUM_T(FRIDGE::OnOffStates), POA_FRIDGE::ROOnOffStates> > FridgeControl::m_powerStatus_sp [private, inherited] |
The fridge can be either turned on or off.
baci::SmartPropertyPointer<baci::RWstring> RampedPowerSupply::m_rampingStatus_sp [private, inherited] |
m_rampingStatus_p is the RampedPowerSupply's status in the ramping process.
DevIO<CORBA::Long>* RampedPowerSupply::m_rampingStep_devio_p [private, inherited] |
m_rampingStep_devio_p is the DevIO subclass passed to the RampingStep property when it is created. Essentially the DevIO is used to interact with hardware directly without tying ACS to any specific hardware drivers resulting in added flexibility. Please see acsexmplLongDevIO.h to understand exactly how this is accomplished.
baci::SmartPropertyPointer<baci::ROlong> RampedPowerSupply::m_rampingStep_sp [private, inherited] |
m_rampingStep_p is the RampedPowerSupply's present step in the ramping process.
baci::SmartPropertyPointer<baci::ROdouble> PowerSupply::m_readback_sp [private, inherited] |
m_readback_sp is the actual value of PowerSupply's current.
baci::SmartPropertyPointer<baci::RWdouble> Door::m_ref_position_sp [private, inherited] |
m_ref_position_sp is the position the Door should be in
baci::SmartPropertyPointer<baci::RWdouble> FridgeControl::m_refTemperature_sp [private, inherited] |
m_refTemperature_sp is the temperature we want the fridge to be.
baci::ROdoubleSeq* AmsTestSeq::m_ROdoubleSeqPM_p [private, inherited] |
m_RWdoubleSeq_p is all the coefficients that the client can set.
baci::RWdoubleSeq* AmsTestSeq::m_RWdoubleSeqPM_p [private, inherited] |
m_ROdoubleSeqPM_p is all the coefficients currently set.
baci::SmartPropertyPointer<baci::ROlong> LampWheel::m_slots_sp [private, inherited] |
m_slots_sp is the number of available slots in the wheel
baci::SmartPropertyPointer<baci::ROlong> FilterWheel::m_slots_sp [private, inherited] |
m_slots_sp is the number of available slots in the wheel
baci::SmartPropertyPointer< ROEnumImpl<ACS_ENUM_T(acsexmplCalendar::StateEnum), POA_acsexmplCalendar::ROStateEnum> > Calendar::m_state_sp [private, inherited] |
m_state_sp represents how good are we with the plan this year...
baci::SmartPropertyPointer<baci::ROpattern> PowerSupply::m_status_sp [protected, inherited] |
m_status_sp is the PowerSupply's state (values are in CDB).
baci::SmartPropertyPointer<baci::ROlong> Door::m_substate_sp [private, inherited] |
m_substate_sp is the state the door is currently in
- See also:
- acsexmplDoorImpl.cpp
baci::SmartPropertyPointer<baci::ROstring> Door::m_version_sp [private, inherited] |
m_version_sp is the Door's current version
baci::SmartPropertyPointer<baci::ROstring> Building::m_version_sp [private, inherited] |
m_version_sp is a string which shows the version of class Building being used.
Descriptor* FilterWheel::m_wheelConfiguration [private, inherited] |
The array describing the actual configuration of the wheel: It is built by reading the CDB The number of item in the array is given by the number of available slots defined in the CDB
baci::SmartPropertyPointer<baci::RWpattern> Calendar::m_yearAttributes_sp [private, inherited] |
m_yearAttributes_sp is the calendar's year "attribute"
unsigned int SlotDescriptor::pos [inherited] |
const int RampedPowerSupply::START_RAMPING = 3 [static, inherited] |
One of these function IDs will be passed to invokeAction().
const int RampedPowerSupply::STOP_RAMPING = 4 [static, inherited] |
unsigned int SlotDescriptor::warmUpTime [inherited] |
unsigned int SlotDescriptor::watt [inherited] |
