Equipment - overview
| Item | Description | Supplier | Order number | Price |
| Large vacuum oven | Heraeus, VT6060M, 53 l, 200 oC | K & K Laborbedarf | 411203993 | 13.480.50 DM |
| Small vacuum oven | Bioblock, 16 l | Novodirect | A45001 | 2.425.- DM |
| Catalysator | Pfeiffer, URB 025 | Pfeiffer | BP-B10750 | 2.070.- DM |
| Cold trap | Pfeiffer, KLF040 | Pfeiffer | PK-Z80008 | 2.740.- DM |
| Ultrasonic bath | Bioblock, 28 l | Novodirect | A86485 | 4.768.- DM |
| Heating bands | Isopad, SiS-10 | Isopad | 03782503 | 256.- DM |
| Laboratory fume hood | Köttermann | K & K Laborbedarf | KOM 2418930, KOM 3509C3, KOM 796... |
11.028.- DM |
| Clean air bench | Holten, Basic | Novodirect | A49793 | 12.219.30 DM |
| Large vacuum pump stand (oil free) forcryostat | Pfeiffer, THS 521 | Pfeiffer | - | 23.186.50 DM |
| Small Dry vacuum pump stand (oil free) for oven | Alcatel, Drytel 31 | Alcatel | 795920 | 11.503.40 DM |
| Leak tester | Pfeiffer, HLT 270 | Pfeiffer | BGZ08010 | 26.000.- DM |
| Residual gas analyser + vacuum pump | Pfeiffer, QMS 200 F2 + THS 521 | Pfeiffer | PTM 03211211 | 35.742.50 DM |
| Cleanroom ionizing air gun | Simco, New Top Gun | CRTM | 4005106 (air gun) 5050696 (filter set) |
2.174.03 DM (air gun) 223.40 DM (filter set) |
| Latex gloves | powder free | Novodirect | A21028 | -.64 DM |
| Cleanroom gloves | soa-tech, PU-coated finger tips | CRTM | B0600-L | 11.20 DM |
| soa-tech, conductive gloves | CRTM | A0100-L | 22.- DM | |
| soa-tech, uncoated | CRTM | B0610-L | 7.20 DM | |
| Thermogrip gloves | - | K & K Laborbedarf | 360124210 | 36.- DM |
| Working gloves | - | Hoffmann Werkzeuge | 08990 | 1.89 DM |
| Eye protection glasses | neoLab | K & K Laborbedarf | 360122074 | 35.70 DM |
| Working clothes | - | - | - | - |
| Security shelf for chemicals | FWF 90 | Novodirect | A34019 | 5.630.- DM |
| Acetone | for analysis, no. 1090 | Bisterfeld | 50007057 | 4.- DM / liter |
| Ethanol | 99 %, Art. no. 642 | Biesterfeld | 53118957 | 3.40 DM / liter |
| iso-Propanol | 97 - 99 %, no. 1219 | Biesterfeld | 50307057 | 2.65 DM / liter |
| Plastic container | 114 l, HDPE | Novodirect | A99162 | 234.- DM |
| 42 l, HDPE | Novodirect | A21633 | 143.- DM | |
| 27 l, HDPE | Novodirect | A21632 | 108.- DM | |
| Optical paper | - | - | - | - |
| Cleaning paper | blue, width = 32 cm | Schäfer-Shop | 73V/97901 | 269.- DM |
| Cleaning tips | - | K & K Laborbedarf | 367883660 | -.21 DM |
| Aluminium foil | neoLab | K & K Laborbedarf | 380116595 | 85.- DM |
| Crucible tongs | - | K & K Laborbedarf | 330502099 | 7.95 DM |
| Laboratory brushes | Set | K & K Laborbedarf | 370117032 | 39.85 DM |
| Master Bond glue | - | Master Bond, USA | EP21TCHT-1 | » 400.- DM |
| Black paint | 3M Velvet Coating | Mankiewicz | 811-21 9218 | 130.- DM |
| 3M Primer | Mankiewicz | 5523 7525 | 38.65 DM |
Precautions - overview
 Precautious experts during the deliciousprocedure. |
Item | Characteristics | Precautions | |
| Avoid this : | Do this : | |||
| Acetone, alcohol | Extremely fire hazardous | Static sparks, open fire |
Wear gloves, wear eye protection glasses, wear a gas mask or use the fume extractor |
|
| CCD | Static sensitive, mechanical sensitive, heat sensitive |
Overbaking | - | |
| Metal parts | Mechanical sensitive | Scratches during working | - | |
| Plastic parts | Heat sensitive | Overbaking, dissolving |
- | |
| Vacuum oven | Heat | Acetone- and alcohol baths nearby | Wear thermal gloves | |
| Heating bands | - | Killing cryostat with overheating | - | |
