XSHOOTER trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2026-09-22T12:37:12 (UT)
  | now: 2026-09-26T10:01:57 (UT) muc02 QC pipeline: xshoo-3.6.5a (installed 2023-09-18)
same group: bias_AGC dark_AGC detmon_AGC
General news: NOTE: The Health Check and calChecker services have been moved to qcFlow. These pages are only maintained for comparison and will be removed in 2026.
XSHOOTER news: Updating of these XSHOOTER HC pages has been stopped. Please refer to the qcFlow Health Check. You can browse the full available trending history here.
Report news:
DATE*: [?] 2026-09-15
report | NLT 		2026-09-16
report | NLT 		2026-09-17
report | NLT 		2026-09-18
report | NLT 		2026-09-19
report | NLT 		2026-09-20
report | NLT 		2026-09-21
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?] 		*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 1.77e+03 ADU 20%± 354 85 median_master this | last_yr | all
2 •QC1DB MEDIAN 0.739 ADU 80%± 0.591 85 struct_x1 this | last_yr | all
3 •QC1DB MEDIAN 4.6 ADU 60%± 2.76 85 ron this | last_yr | all
4 •QC1DB MEDIAN 0.845 ADU 60%± 0.507 85 struct_y1 this | last_yr | all
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 8|
data source:xshooter_bias
(QC1 database)
dataset:median_master•
median:1.77e+03ADU
rel. thresholds: ±20%1415.714844...2123.572266ADU
N_data plotted:85
[click plot for closeup]
Plot 3
scores: 8|
data source:xshooter_bias
(QC1 database)
dataset:ron•
median:4.6ADU
rel. thresholds: ±60%1.8385636...7.3542544ADU
N_data plotted:85
[click plot for closeup]
Plot 2
scores: not implemented
data source:xshooter_bias
(QC1 database)
dataset:struct_x1•
median:0.739ADU
rel. thresholds: ±80%0.1478458...1.3306122ADU
N_data plotted:85
[click plot for closeup]
Plot 4
scores: not implemented
data source:xshooter_bias
(QC1 database)
dataset:struct_y1•
median:0.845ADU
rel. thresholds: ±60%0.338018...1.352072ADU
N_data plotted:85
[click plot for closeup]
This plot

This plots shows detector related QC parameters derived from BIAS health check calibrations of the xshooter acquisition and guiding camera (AGC). It is a 562 x 528 pixel technical CCD. For the definition of the QC parameters, please see the corresponding section of the UVB-arm and VIS-arm science detector. On 2014-01-09 the detector operations mode was switched from DET.OUT1.GAININD = 8 to DET.OUT1.GAININD = 4.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
