#include <acscourseMount5Impl.h>
Public Member Functions | |
| Mount5Impl (const ACE_CString &name, maci::ContainerServices *containerServices) | |
| virtual | ~Mount5Impl () |
| virtual void | objfix (CORBA::Double az, CORBA::Double elev) |
| virtual ACS::ROdouble_ptr | cmdAz () |
| virtual ACS::ROdouble_ptr | cmdEl () |
| virtual ACS::ROdouble_ptr | actAz () |
| virtual ACS::ROdouble_ptr | actEl () |
Protected Attributes | |
| baci::SmartPropertyPointer < baci::ROdouble > | m_cmdAz_sp |
| baci::SmartPropertyPointer < baci::ROdouble > | m_cmdEl_sp |
| baci::SmartPropertyPointer < baci::ROdouble > | m_actAz_sp |
| baci::SmartPropertyPointer < baci::ROdouble > | m_actEl_sp |
Private Member Functions | |
| void | operator= (const Mount5Impl &) |
Private Attributes | |
| nc::SimpleSupplier * | m_MountSupplier_p |
| nc::SimpleConsumer < ACSCOURSE_MOUNT::MountEventData > * | m_simpConsumer_p |
Constructor & Destructor Documentation
| Mount5Impl::Mount5Impl | ( | const ACE_CString & | name, | |
| maci::ContainerServices * | containerServices | |||
| ) |
Constructor Nearly identical to the Mount1 C++ class's implementation except that it instantiates both event supplier and consumer objects.
- Parameters:
-
name component's name. containerServices the container services object for this component
| virtual Mount5Impl::~Mount5Impl | ( | ) | [virtual] |
Destructor Nearly identical to the Mount1 C++ class's implementation except that it destroys the event supplier and consumer objects.
Member Function Documentation
| virtual ACS::ROdouble_ptr Mount5Impl::actAz | ( | ) | [virtual] |
Returns a reference to the actAz property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property actAz
| virtual ACS::ROdouble_ptr Mount5Impl::actEl | ( | ) | [virtual] |
Returns a reference to the actEl property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only double property actEl
| virtual ACS::ROdouble_ptr Mount5Impl::cmdAz | ( | ) | [virtual] |
Returns a reference to the cmdAz property Implementation of IDL interface for the property.
- Returns:
- pointer to read-write double property cmdAz
| virtual ACS::ROdouble_ptr Mount5Impl::cmdEl | ( | ) | [virtual] |
Returns a reference to the cmdEl property Implementation of IDL interface for the property.
- Returns:
- pointer to read-only write property cmdEl
| virtual void Mount5Impl::objfix | ( | CORBA::Double | az, | |
| CORBA::Double | elev | |||
| ) | [virtual] |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation. The actual az and elev values are written to the properties cmdAz, cmdEl, actAz and actEl.
- Parameters:
-
az position azimuth (degree) elev position elevation (degree)
- Exceptions:
-
ACSErrTypeACSCourse::TargetOutOfRangeEx
- Returns:
- void
| void Mount5Impl::operator= | ( | const Mount5Impl & | ) | [private] |
ALMA C++ coding standards state copy operators should be disabled.
Member Data Documentation
m_actAz_p is the antenna's actual azimuth
m_actEl_p is the antenna's actual elevation
m_cmdAz_p is the antenna's commanded azimuth
m_cmdEl_p is the antenna's commanded elevation
nc::SimpleSupplier* Mount5Impl::m_MountSupplier_p [private] |
This is the Supplier class used to publish data to the event channel.
nc::SimpleConsumer<ACSCOURSE_MOUNT::MountEventData>* Mount5Impl::m_simpConsumer_p [private] |
This is the Consumer class used to consumer data from the event channel. The templated parameter is the type of event that will be subscribed to.
The documentation for this class was generated from the following file:
