Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
2.91e+04 |
ADU |
VAL | 20000,35000 |
17 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, the counts in the brighest flat used for the analysis, average over all 16 detectors |
| 2 |
• | QC1DB |
MEDIAN |
2.95e+04 |
ADU |
none | |
272 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, values of all detetcors |
| 2 |
• | QC1DB |
none |
|
ADU |
none | |
17 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, values for detector 5 |
| 2 |
• | QC1DB |
none |
|
ADU |
none | |
17 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, values for detector 6 |
| 2 |
• | QC1DB |
none |
|
ADU |
none | |
17 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, values for detector 1 |
| 2 |
• | QC1DB |
none |
|
ADU |
none | |
17 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, values for detector 7 |
| 3 |
• | QC1DB |
MEDIAN |
3.52e+03 |
ADU |
VAL | 3200,4500 |
17 |
qc_line_medmax |
this |
last_yr |
all
|
LINE_MEDMAX, stdev over all detectors |
| 4 |
■ | LOCAL |
none |
|
ADU |
none | |
264 |
qc_line_medmax |
n/a |
Score per Detector: Green = within the thresholds |
| 4 |
■ | LOCAL |
none |
|
ADU |
none | |
8 |
qc_line_medmax |
n/a |
Score per Detector: Red = beyond thresholds |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores:  4|
| | data source: | vircam_line
(QC1 database) |
| dataset: | qc_line_medmax | • |
| median: | 2.91e+04 | ADU |
| fixed thresholds: | 20000...35000 | ADU |
| N_data plotted: | 17 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | vircam_line
(QC1 database) |
dataset:
(numbers below apply to this dataset) | qc_line_medmax | • |
| median: | 2.95e+04 | ADU |
| thresholds: | none | |
| N_data plotted: | 272 |
| [click plot for closeup] |
Plot 3
scores: 4|
| | data source: | vircam_line
(QC1 database) |
| dataset: | qc_line_medmax | • |
| median: | 3.52e+03 | ADU |
| fixed thresholds: | 3200...4500 | ADU |
| N_data plotted: | 17 |
| [click plot for closeup] |
Plot 4
scores: not implemented
| | data source: | local data source
|
dataset:
(numbers below apply to this dataset) | qc_line_medmax | ■ |
| average: | none |
| thresholds: | none |
| N_data plotted: | 264 |
| [click plot for closeup] |
The scoring thresholds of the individual chips used in box (4) are:
| CHIP_16 | 15000 | 40000 |
| CHIP_15 | 15000 | 40000 |
| CHIP_14 | 15000 | 40000 |
| CHIP_13 | 15000 | 40000 |
| CHIP_12 | 15000 | 40000 |
| CHIP_11 | 15000 | 40000 |
| CHIP_10 | 15000 | 40000 |
| CHIP_9 | 15000 | 40000 |
| CHIP_8 | 15000 | 40000 |
| CHIP_7 | 15000 | 40000 |
| CHIP_6 | 15000 | 40000 |
| CHIP_5 | 15000 | 40000 |
| CHIP_4 | 15000 | 40000 |
| CHIP_3 | 15000 | 40000 |
| CHIP_2 | 15000 | 40000 |
| CHIP_1 | 15000 | 40000 |
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
