SINFONI trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2019-06-28T05:02:23 (UT)
  | now: 2024-10-31T23:23:33 (UT) muc04 QC pipeline: sinfo-3.2.5 (installed 2019-05-09)
same group: wavelength res_power   slit_pos#17 fwhm_lines N_lines lamp_mean lamp_max
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
SINFONI news: 2019-06-26: SINFONI taken out of operations
Report news:
DATE*: [?] 2019-06-24
report | NLT
2019-06-25
report | NLT
2019-06-26
no data | NLT
2019-06-27
no data | NLT
2019-06-28
no data | NLT
2019-06-29
no data | NLT
2019-06-30
no data | NLT
r...
Raw CAL displays:
raw raw no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files
P...
CAL product quality:
products products no CAL products no CAL products no CAL products no CAL products no CAL products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 oQC1DB MEDIAN 15 number VAL14,16 71 qc_wave_all this | last_yr | all number of identified spectral lines in J-band at ALL camera scales
(this FULL data set is scored)
1 QC1DB none   number none  35 qc_wave_all this | last_yr | all number of identified spectral lines: J-band/250 mas scale
1 QC1DB none   number none  18 qc_wave_all this | last_yr | all number of identified spectral lines: J-band/100 mas scale
1 QC1DB none   number none  18 qc_wave_all this | last_yr | all number of identified spectral lines: J-band/25 mas scale

2 oQC1DB MEDIAN 28 number VAL27,29 73 qc_wave_all this | last_yr | all number of identified spectral lines in H-band at ALL camera scales
(this FULL data set is scored)
2 QC1DB none   number none  34 qc_wave_all this | last_yr | all number of identified spectral lines: H-band/250 mas scale
2 QC1DB none   number none  21 qc_wave_all this | last_yr | all number of identified spectral lines: H-band/100 mas camera scale
2 QC1DB none   number none  18 qc_wave_all this | last_yr | all number of identified spectral lines: H-band/25 mas camera scale

3 oQC1DB MEDIAN 25 number VAL24,26 112 qc_wave_all this | last_yr | all number of identified spectral lines in the K-band at ALL camera scales
(this FULL data set is scored)
3 QC1DB none   number none  47 qc_wave_all this | last_yr | all number of identified spectral lines: K-band/250 mas camera scale
3 QC1DB none   number none  28 qc_wave_all this | last_yr | all number of identified spectral lines: K-band/100 mas camera scale
3 QC1DB none   number none  37 qc_wave_all this | last_yr | all number of identified spectral lines: K-band/25 mas camera scale

4 oQC1DB MEDIAN 20 number VAL19,21 78 qc_wave_all this | last_yr | all number of identified spectral lines in the H+K-band at ALL camera scales
(this FULL data set is scored)
4 QC1DB none   number none  31 qc_wave_all this | last_yr | all number of identified spectral lines: H+K-band/250 mas camera scale
4 QC1DB none   number none  20 qc_wave_all this | last_yr | all number of identified spectral lines: H+K-band/100 mas camera scale
4 QC1DB none   number none  27 qc_wave_all this | last_yr | all number of identified spectral lines: H+K-band/25 mas camera scale
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 4|
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_wave_allo
median:15number
fixed thresholds:14...16number
N_data plotted:71
[click plot for closeup]
Plot 2
scores: 7|
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_wave_allo
median:28number
fixed thresholds:27...29number
N_data plotted:73
[click plot for closeup]
Plot 3
scores: 10|
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_wave_allo
median:25number
fixed thresholds:24...26number
N_data plotted:112
[click plot for closeup]
Plot 4
scores: 6|
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_wave_allo
median:20number
fixed thresholds:19...21number
N_data plotted:78
[click plot for closeup]
General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
