SINFONI trending system: HEALTH CHECK report LINE

General news:	NOTE: The Health Check and calChecker services have been moved to qcFlow. These pages are only maintained for comparison and will be removed in 2026.
SINFONI news:	2019-06-26: SINFONI taken out of operations
Report news:

DATE*: [?]

2019-06-24
report | NLT

2019-06-25
report | NLT

2019-06-26
no data | NLT

2019-06-27
no data | NLT

2019-06-28
no data | NLT

2019-06-29
no data | NLT

2019-06-30
no data | NLT

r...

Raw CAL displays:

raw

no CAL raw files

P...

CAL product quality:

products

no CAL products

transfer

ngas

[?]

scores&comments |

FULL | history ... | plot tutorial ... | contact | HC_docu... [?]

*Date on this monitor changes at 21:00 UT

png:	Information and research:
- png file	- advanced studies: QC1 browser \| QC1 plotter

Plot
?

Symb
?

Source
*

Average ?

Thresholds ?

N_
data

QC1
parameter

Data
downloads

Remarks

method

value

unit

method

value

•

QC1DB

MEDIAN

0.998

unitless

VAL

0.9,1.2

qc_bpm_lin1_mean

this | last_yr | all

J-band linearity coefficient (mean) C1 (nlin(x) = C0 + C1x + C2x^2 + C3x^3) (only for the 25 mas camera scale)

•

QC1DB

MEDIAN

1.02

unitless

VAL

0.9,1.2

qc_bpm_lin1_mean

this | last_yr | all

H-band linearity coefficient (mean) C1

•

QC1DB

MEDIAN

1.04

unitless

VAL

0.9,1.2

qc_bpm_lin1_mean

this | last_yr | all

K-band linearity coefficient (mean) C1

•

QC1DB

MEDIAN

1.09

unitless

VAL

0.9,1.2

qc_bpm_lin1_mean

this | last_yr | all

H+K-band linearity coefficient (mean) C1

*Data sources: QC1DB: QC1 database; LOCAL: local data source

Plot 1 scores: 1\|
data source:	sinfoni_line (QC1 database)
dataset:	qc_bpm_lin1_mean	•
median:	0.998	unitless
fixed thresholds:	0.9...1.2	unitless
N_data plotted:	8
[click plot for closeup]

Plot 2 scores: 1\|
data source:	sinfoni_line (QC1 database)
dataset:	qc_bpm_lin1_mean	•
median:	1.02	unitless
fixed thresholds:	0.9...1.2	unitless
N_data plotted:	8
[click plot for closeup]

Plot 3 scores: 2\|
data source:	sinfoni_line (QC1 database)
dataset:	qc_bpm_lin1_mean	•
median:	1.04	unitless
fixed thresholds:	0.9...1.2	unitless
N_data plotted:	11
[click plot for closeup]

Plot 4 scores: 1\|
data source:	sinfoni_line (QC1 database)
dataset:	qc_bpm_lin1_mean	•
median:	1.09	unitless
fixed thresholds:	0.9...1.2	unitless
N_data plotted:	10
[click plot for closeup]

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
