MATISSE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2026-04-17T09:54:47 (UT)
  | now: 2026-04-17T10:50:51 (UT) muc12 QC pipeline: matisse-2.0.2 (installed 2024-11-28)
same group: VIS2_LM-LOW N CP_LM N DP_LM N SNR_LM N
General news: NOTE: The Health Check and calChecker services have been moved to qcFlow. These pages are only maintained for comparison and will be removed in 2026.
MATISSE news:
Report news: 2022-02-20 Bug in the software. MATISSE Team is aware of this. Working on it.
2023-02-26: the issue seems solved : this was not an pipeline issue but a SHIFT MAP not updated after the switch of lamps (IPE) [ccid@eso.org]
DATE*: [?] 2026-04-10
report | NLT 		2026-04-11
report | NLT 		2026-04-12
report | NLT 		2026-04-13
report | NLT 		2026-04-14
report | NLT 		2026-04-15
report | NLT 		2026-04-16
report | NLT
r...
Raw CAL displays:
n/a n/a n/a n/a n/a n/a n/a
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial: n/a | contact | HC_docu... | quality events...                 daily/often; important to check     [?] 		*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 1.43e+03 NONE VAL200,1800 92 snr_vis2_bas2 this | last_yr | all Internal SNR Baseline 12 - HAWAII-R2G (MATISSE-LM) - LOW
2 •QC1DB MEDIAN 1.17e+03 NONE VAL200,1800 92 snr_vis2_bas5 this | last_yr | all Internal SNR Baseline13
3 •QC1DB MEDIAN 1.13e+03 NONE VAL100,1685 92 snr_vis2_bas6 this | last_yr | all Internal SNR Baseline14
4 •QC1DB MEDIAN 1.39e+03 NONE VAL200,1800 92 snr_vis2_bas3 this | last_yr | all Internal SNR Baseline23
5 •QC1DB MEDIAN 1.32e+03 NONE VAL100,1685 92 snr_vis2_bas4 this | last_yr | all Internal SNR Baseline24
6 •QC1DB MEDIAN 1.45e+03 NONE VAL200,1800 92 snr_vis2_bas1 this | last_yr | all Internal SNR Baseline34
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 5|
data source:matisse_internal_vis
(QC1 database)
dataset:snr_vis2_bas2•
median:1.43e+03NONE
fixed thresholds:200...1800NONE
N_data plotted:92
[click plot for closeup]
Plot 2
scores: 5|
data source:matisse_internal_vis
(QC1 database)
dataset:snr_vis2_bas5•
median:1.17e+03NONE
fixed thresholds:200...1800NONE
N_data plotted:92
[click plot for closeup]
Plot 3
scores: 5|
data source:matisse_internal_vis
(QC1 database)
dataset:snr_vis2_bas6•
median:1.13e+03NONE
fixed thresholds:100...1685NONE
N_data plotted:92
[click plot for closeup]
Plot 4
scores: 5|
data source:matisse_internal_vis
(QC1 database)
dataset:snr_vis2_bas3•
median:1.39e+03NONE
fixed thresholds:200...1800NONE
N_data plotted:92
[click plot for closeup]
Plot 5
scores: no current data
data source:matisse_internal_vis
(QC1 database)
dataset:snr_vis2_bas4•
median:1.32e+03NONE
fixed thresholds:100...1685NONE
N_data plotted:92
[click plot for closeup]
Plot 6
scores: 5|
data source:matisse_internal_vis
(QC1 database)
dataset:snr_vis2_bas1•
median:1.45e+03NONE
fixed thresholds:200...1800NONE
N_data plotted:92
[click plot for closeup]
General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
