FORS2 trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-10-31T17:18:28 (UT)
  | now: 2024-10-31T23:35:58 (UT) muc01 QC pipeline: fors-5.6.10 (installed 2024-04-19)
same group: SCR_FF_RI SCR_FF_uv SCR_FF_b   SCR_FF_RMS_RI SCR_FF_RMS_uv SCR_FF_RMS_b
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
FORS2 news:
Report news:
DATE*: [?] 2024-10-24
report | NLT
2024-10-25
report | NLT
2024-10-26
report | NLT
2024-10-27
report | NLT
2024-10-28
report | NLT
2024-10-29
report | NLT
2024-10-30
report | NLT
2024-10-31
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products products no CAL products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 207 ADU VAL150,400 21 efficiency this | last_yr | all lamp flux in ADU/sec for R_SPECIAL, chip 1
2 QC1DB MEDIAN 199 ADU VAL150,400 21 efficiency this | last_yr | all lamp flux in ADU/sec for R_SPECIAL, chip 2
3 QC1DB MEDIAN 2.24e+04 ADU VAL21000,30000 21 efficiency this | last_yr | all lamp flux in ADU/sec for I_BESS, chip 1
4 QC1DB MEDIAN 2.29e+04 ADU VAL21000,30000 21 efficiency this | last_yr | all lamp flux in ADU/sec for I_BESS, chip 2
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 2|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:207ADU
fixed thresholds:150...400ADU
N_data plotted:21
[click plot for closeup]
Plot 2
scores: 2|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:199ADU
fixed thresholds:150...400ADU
N_data plotted:21
[click plot for closeup]
Plot 3
scores: 2|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:2.24e+04ADU
fixed thresholds:21000...30000ADU
N_data plotted:21
[click plot for closeup]
Plot 4
scores: 2|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:2.29e+04ADU
fixed thresholds:21000...30000ADU
N_data plotted:21
[click plot for closeup]
This plot

The FlatBlue+1 and FlatBlue+2 lamps are used for imaging screen flats.
The RMS is calculated from the master screen flat image pixel sample (2x2 binning) X: @200 @1800 and Y: @400 @800 covering the unvignetted area of chip1 and chip2.

DB Name: fors2_scrflat
TPL.ID: FORS2_img_cal_scrflat
QC1 DB parameter: efficiency


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
