GRAVITY trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2026-04-16T18:31:43 (UT)
  | now: 2026-04-17T07:59:54 (UT) muc05 QC pipeline: gravity-1.5.4 (installed 2022-03-24)
same group: SC_low SC_med SC_high
General news: NOTE: The Health Check and calChecker services have been moved to qcFlow. These pages are only maintained for comparison and will be removed in 2026.
GRAVITY news:
Report news:
DATE*: [?] 2026-04-10
report | NLT 		2026-04-11
report | NLT 		2026-04-12
report | NLT 		2026-04-13
report | NLT 		2026-04-14
report | NLT 		2026-04-15
report | NLT 		2026-04-16
no data | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products no CAL products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?] 		*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 12.7 pixel VAL12.60,12.90 105 profile_center_sc1 this | last_yr | all center of 1st flat-field profile, SPLIT polarisation
2 •QC1DB MEDIAN 160 pixel none  105 profile_center_sc13 this | last_yr | all center of 13th flat-field profile, SPLIT polarisation
3 •QC1DB MEDIAN 0.608 pixel VAL0.59,0.61 105 profile_width_sc1 this | last_yr | all width of 1st flat-field profile, SPLIT polarisation
4 •QC1DB MEDIAN 0.555 pixel none  105 profile_width_sc13 this | last_yr | all width of 13th flat-field profile, SPLIT polarisation
5 •QC1DB MEDIAN 4.66 pixel VAL4.6,4.8 54 profile_center_sc1 this | last_yr | all center of 1st flat-field profile, COMBINED polarisation
6 •QC1DB MEDIAN 150 pixel none  54 profile_center_sc13 this | last_yr | all center of 13th flat-field profile, COMBINED polarisation
7 •QC1DB MEDIAN 0.617 pixel VAL0.60,0.62 54 profile_width_sc1 this | last_yr | all width of 1st flat-field profile, COMBINED polarisation
8 •QC1DB MEDIAN 0.534 pixel none  54 profile_width_sc13 this | last_yr | all width of 13th flat-field profile, COMBINED polarisation
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 7|
data source:gravity_p2vm
(QC1 database)
dataset:profile_center_sc1•
median:12.7pixel
fixed thresholds:12.6...12.9pixel
N_data plotted:105
[click plot for closeup]
Plot 2
scores: not implemented
data source:gravity_p2vm
(QC1 database)
dataset:profile_center_sc13•
median:160pixel
thresholds:none
N_data plotted:105
[click plot for closeup]
Plot 3
scores: 7|
data source:gravity_p2vm
(QC1 database)
dataset:profile_width_sc1•
median:0.608pixel
fixed thresholds:0.59...0.61pixel
N_data plotted:105
[click plot for closeup]
Plot 4
scores: not implemented
data source:gravity_p2vm
(QC1 database)
dataset:profile_width_sc13•
median:0.555pixel
thresholds:none
N_data plotted:105
[click plot for closeup]
Plot 5
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:profile_center_sc1•
median:4.66pixel
fixed thresholds:4.6...4.8pixel
N_data plotted:54
[click plot for closeup]
Plot 6
scores: not implemented
data source:gravity_p2vm
(QC1 database)
dataset:profile_center_sc13•
median:150pixel
thresholds:none
N_data plotted:54
[click plot for closeup]
Plot 7
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:profile_width_sc1•
median:0.617pixel
fixed thresholds:0.6...0.62pixel
N_data plotted:54
[click plot for closeup]
Plot 8
scores: not implemented
data source:gravity_p2vm
(QC1 database)
dataset:profile_width_sc13•
median:0.534pixel
thresholds:none
N_data plotted:54
[click plot for closeup]
This plot

Cross-dispersion profiles in flat fields: central position and width of the 1st and 13th profile.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
